3 1/2" SUPER HEAVY DUTY ROLLER CONVEYORS... |
|
|
| Roller Centers (inches) | MODEL NUMBER | Over-All Width (inches) | Between Rail Width (inches) | WEIGHT | |
|---|---|---|---|---|---|
| 5 ft. Section (lbs.) | 10 ft. Section (lbs.) | ||||
| 4 | 350-SRH-0412 | 12 | 8 | 263 | 515 |
| 350-SRH-0418 | 18 | 14 | 346 | 680 | |
| 350-SRH-0424 | 24 | 20 | 434 | 855 | |
| 350-SRH-0430 | 30 | 26 | 522 | 1025 | |
| 8 | 350-SRH-0812 | 12 | 8 | 178 | 346 |
| 350-SRH-0818 | 18 | 14 | 225 | 435 | |
| 350-SRH-0824 | 24 | 20 | 273 | 522 | |
| 350-SRH-0830 | 30 | 26 | 320 | 610 | |
| 12 | 350-SRH-1212 | 12 | 8 | 152 | 290 |
| 350-SRH-1218 | 18 | 14 | 185 | 350 | |
| 350-SRH-1224 | 24 | 20 | 220 | 415 | |
| 350-SRH-1230 | 30 | 26 | 248 | 473 | |
