| 1 3/8" ROLLER CONVEYORS... |
These 1 3/8" diameter gravity roller conveyors
are extremely popular and are a standard in the industry. Ideal for the movement
of light-medium weight packages. They are easily portable and can be used as a
temporary or a permanent conveyor line.
GENERAL SPECIFICATIONS
- Rollers: 1 3/8", 18 Gauge
Galvanized./Alum.
- Axles: 1/4" Round, Spring Loaded
- Frame: 2 1/2" x 1" x 1", 12
Gauge Galv. or 1/8" Alum. Formed Channel
- 5 Cross Braces
- Hook and Rod Couplers Standard
- Frame Capacity over 10'--Steel: 50 lbs./ft,
Alum.: 30 lbs./ft.
- Roller Capacity--Steel: 50 lbs., Alum.: 40
lbs.; over 5' Steel: 200 lbs./ft., Alum: 100 lbs./ft.
"138-SR"
SERIES GALVANIZED STEEL
| Roller
Centers (inches) |
MODEL
NUMBER |
Over-All
Width (inches) |
Between
Rail Width (inches) |
WEIGHT |
| 5 ft. Section
(lbs.) |
10 ft. Section
(lbs.) |
| 1
1/2 |
138-SR-1512 |
12 |
10 |
61 |
111 |
| 138-SR-1515 |
15 |
13 |
71 |
130 |
| 138-SR-1518 |
18 |
16 |
81 |
148 |
| 138-SR-1520 |
20 |
18 |
89 |
161 |
| 138-SR-1524 |
24 |
22 |
102 |
186 |
| 3 |
138-SR-0312 |
12 |
10 |
41 |
74 |
| 138-SR-0315 |
15 |
13 |
46 |
84 |
| 138-SR-0318 |
18 |
16 |
52 |
94 |
| 138-SR-0320 |
20 |
18 |
55 |
100 |
| 138-SR-0324 |
24 |
22 |
63 |
114 |
| 4
1/2 |
138-SR-4512 |
12 |
10 |
34 |
61 |
| 138-SR-4515 |
15 |
13 |
38 |
69 |
| 138-SR-4518 |
18 |
16 |
42 |
76 |
| 138-SR-4520 |
20 |
18 |
44 |
80 |
| 138-SR-4524 |
24 |
22 |
50 |
90 |
| 6 |
138-SR-0612 |
12 |
10 |
30 |
55 |
| 138-SR-0615 |
15 |
13 |
33 |
60 |
| 138-SR-0618 |
18 |
16 |
36 |
66 |
| 138-SR-0620 |
20 |
18 |
38 |
70 |
| 138-SR-0624 |
24 |
22 |
42 |
77 |
| 12 |
138-SR-1212 |
12 |
10 |
25 |
46 |
| 138-SR-1215 |
15 |
13 |
27 |
50 |
| 138-SR-1218 |
18 |
16 |
29 |
53 |
| 138-SR-1220 |
20 |
18 |
31 |
56 |
| 138-SR-1224 |
24 |
22 |
33 |
60 |
"138-AR"
SERIES ALUMINUM
| Roller
Centers (inches) |
MODEL
NUMBER |
Over-All
Width (inches) |
Between
Rail Width (inches) |
WEIGHT |
| 5 ft. Section
(lbs.) |
10 ft. Section
(lbs.) |
| 1
1/2 |
138-AR-1512 |
12 |
10 |
34 |
62 |
| 138-AR-1515 |
15 |
13 |
39 |
71 |
| 138-AR-1518 |
18 |
16 |
44 |
80 |
| 138-AR-1520 |
20 |
18 |
47 |
86 |
| 138-AR-1524 |
24 |
22 |
54 |
99 |
| 3 |
138-AR-0312 |
12 |
10 |
22 |
40 |
| 138-AR-0315 |
15 |
13 |
25 |
45 |
| 138-AR-0318 |
18 |
16 |
27 |
50 |
| 138-AR-0320 |
20 |
18 |
29 |
53 |
| 138-AR-0324 |
24 |
22 |
33 |
60 |
| 4
1/2 |
138-AR-4512 |
12 |
10 |
18 |
32 |
| 138-AR-4515 |
15 |
13 |
20 |
36 |
| 138-AR-4518 |
18 |
16 |
22 |
40 |
| 138-AR-4520 |
20 |
18 |
24 |
43 |
| 138-AR-4524 |
24 |
22 |
36 |
48 |
| 6 |
138-AR-0612 |
12 |
10 |
15 |
28 |
| 138-AR-0615 |
15 |
13 |
18 |
32 |
| 138-AR-0618 |
18 |
16 |
19 |
35 |
| 138-AR-0620 |
20 |
18 |
20 |
37 |
| 138-AR-0624 |
24 |
22 |
23 |
42 |
| 12 |
138-AR-1212 |
12 |
10 |
13 |
24 |
| 138-AR-1215 |
15 |
13 |
15 |
27 |
| 138-AR-1218 |
18 |
16 |
16 |
29 |
| 138-AR-1220 |
20 |
18 |
17 |
31 |
| 138-AR-1224 |
24 |
22 |
18 |
33 |
